XJ/TJ/LJ/ZJ to JK Dana 44 Front Axle Swap Truss

XJ/TJ/LJ/ZJ to JK Dana 44 Front Axle Swap Truss
    Details
    Price:
    $491.14
    Code: 14118
    Weight: 55.00 pounds
    Rating:
    Ratings Snapshot
    4.0
    out of 5
    5 (0)
    4 (1)
    3 (0)
    2 (0)
    1 (0)
    Value 3.0
    Quality 3.0
    Service 5.0
    Would recommend this product.
    100%
    Add To Wishlist

    Would you like to put a JK Dana 44 front axle under your XJ/TJ/LJ/ZJ?  Iron Rock Off Road has engineered a swap truss that makes this swap simple.

    Why would you want to do this swap?
    • It's a Mammoth strength upgrade.  Your Dana 30 ring gear is 7.125" and the JK axle is 8.5"
    • Huge braking upgrade
    • 5" width gain for better stability and lower center of gravity
    • High pinion JK 44's deliver huge driveshaft angle reduction when compared to standard Dana 30 low pinion axles

    Key Product Features:
    • Coil pad locations optimized for the XJ/ZJ/TJ/LJ
    • Integrated coil retainer plates
    • High strength/low profile C to C truss
    • Upper and lower C gussets
    • Combination of 3/16",1/4", and 3/8" thick plate steel
    • Tab and slot construction for easy assembly
    • Shock mounts are moved outboard and eliminate bar pins
    • Lower control arm brackets are super high clearance, tucked up to the bottom of the main axle tube

    Key Product Notes:
    • This swap requires a custom track bar and steering drag link
    • Requires 5 on 5 wheels or wheel spacer adapters and 17" diameter wheels (we have fit some 16s)
    • Works with short arm kits, and IRO ROCK-LINK long arm kits.

    Detailed Installation Instructions

    Estimated Installation Time: 4-6hrs - does not include time for axle removal and installation

    Difficulty Level: 4


    Difficulty Legend

    1 - Kit includes basic components.

    2 - Kit includes little to no adjustable components.

    3 - Kit includes many adjustable components; may require drilling/cutting.

    4 - Kit includes many adjustable components; requires welding; may require drilling/cutting.


    NOTE - Labor Time and Difficulty Level assumes vehicle and/or hardware is in good condition.

    Customer Ratings & Reviews

    1
    Ratings Snapshot
    4.0
    out of 5
    5 (0)
    4 (1)
    3 (0)
    2 (0)
    1 (0)
    Value 3.0
    Quality 3.0
    Service 5.0
    Would recommend this product.
    100%
    4.0
    out of 5
    5 (0)
    4 (1)
    3 (0)
    2 (0)
    1 (0)
    Value 3.0
    Quality 3.0
    Service 5.0
    Would recommend this product.
    100%
    1 Total Reviews
    Disappointed in workmanship
    4 out of 5
    Rjones
    Location: Michigan
    Date: January 12, 2021
    Was very excited when I ordered this product. Very disappointed when I received it. The quality of metal is good but the quality in workmanship is poor. Every corner and edge on every part was razor sharp. Nothing was de burred. There is no reason it should be this sharp. I cut my hand when unboxing because of the sharp corners. I had high expectations because I have ordered from here before and I like the company and products but this isn’t worth the price. I shouldn’t have to sit down and spend hours de burring the metal correctly. When I spend this much it should already be done.
    Recommended
    Value 3
    Quality 3
    Service 5
    1 Total Reviews
