***BILSTEIN SHOCKS ARE IN LIMITED SUPPLY. BACKORDERS MAY OCCUR.***
NOW WITH ADJUSTABLE CONTROL ARMS!
Durability and comfort were the design elements we based this kit upon. Whether you are cruising the interstate at 75mph or driving on the boulders of your favorite trail, this kit delivers performance. On the street, you may forget the fact that you are driving a lifted XJ! Off road you'll appreciatethe ground clearance gains and the ability to run a larger tire size.
BENEFITS:- Increased ground clearance
- Run 32" tires
- Rubber bushings for great ride quality and flex
- Our own leaf springs made with the highest quality manufacturing proceduresin the spring business.
- Nitrogen charged shock absorbers
- XJ's have great caster adjustment without the need for more expensive adjustable control arms.
KIT INCLUDES:- New front coil springs
- New rear leaf springs
- Adjustable Double Shear Track Bar
- Heavy duty track bar drop bracket
- Heavy duty adjustable lower control arms
- Heavy duty adjustable upper control arms
- Extended front sway bar links
- Rear spring shackle
- Transfer case drop kit
- All necessary hardware
INSTRUCTIONS:
NOTE:- SYE and CV driveshaft recommended with this lift.
- Use of a shacle relocation bracket will void the warranty of the leaf pack.
Click on thumbnails for larger pictures.
Recommended
tire size: 32"x11.50" – or metric equivalent
Recommended wheel backspacing: 4.5-6"
TRIMMING MAY BE REQUIRED
Larger tire sizes possible with bumper/fender trimming and/or extended bump
stops.
Estimated Installation
Time: 8-10hrs
Difficulty Level: 2
Difficulty Legend
1
- Kit includes basic components.
2
- Kit includes little to no adjustable components.
3
- Kit includes many adjustable components; may require drilling/cutting.
4
- Kit includes many adjustable components; requires welding; may require
drilling/cutting.
NOTE -
Labor Time and Difficulty Level assumes vehicle and/or hardware is in good
condition.
